Model | DBH D6 | |
Sensor Specifications | Type | VOx Uncooled |
Resolution, pixels | 640×512 | |
Pixel pitch, μm | 12 | |
NETD, mK | <20 | |
Frame Rate, Hz | 60 | |
Optical Specifications | Objective Lens,mm | 60 F1.0 |
Optic Zoom, x | 3 | |
Field of View, degrees / yd @ 100 yd | 7.3°×5.8° | |
Digital Zoom, x | 1 to 6 | |
Eye Relief, mm | 60 | |
Diopter Adjustment, D | -5 to +2 | |
Detection Range, m/yd | 3280 | |
Display Specifications | Type | OLED |
Resolution, pixels | 2560 x 2560 | |
Wi-Fi | Wireless Protocol | Wi-Fi |
Frequency, GHz | 2.4GHz | |
Video Recorder | Video / Photo Resolution, pixel | 1280×1280 |
Video / Photo Format | .mp4 / .jpg | |
Built-in Memory, GB | 64 | |
Physical Specifications | Degree of Protection, IP code | IP67 |
Operating Temperature Range, °F | -13 to+122 | |
Weight, lb | 2.9 | |
Dimensions, inch | 10.3×3.3×3.8 | |
Connections and Compatibilities | Battery Type | 18650 |
Capacity, mAh | 3200 | |
Operating Time on Battery Pack (at t=72°F), h | 8 | |
External Power Supply, V | 5V (Type C USB) | |
Max Recoil Power on Rifled Weapon (Eo), g/Joules | 1000g/6000Joules | |
Ballistic calculation | Yes |
This scope has many things that other scopes on the market don't. The screen is the most forgiving, letting you have your eye inches behind the rubber eyecup and still seeing the entire screen. This scope works great on both AR style rifles as well as bolt action style rifles. The dual 18650 batteries with a long 8 hour runtime as well as an excellent rangefinder that ranges a person at 1000 yards is one of the best.
